Websockets for Hardware Engineers – Part 1

Before we start, what is HTTP? #

This is what HTTP REST looks like…ClientServerIdentify Yourself!SSL HandshakeAuthenticateAuthorizeMake a RequestAsk for dataSend dataTypical Client-Server FlowClientServerIdentify Yourself!SSL HandshakeAuthenticateAuthorizeMake a RequestSend dataAcknowledgeA bit later…

We noticed some issues… #

  • Each request is preceded by an SSL handshake (if HTTPS) and authentication
  • This can consume significant resources (CPU, time, memory) each time
  • The server can never send data to the client
    • The client needs to implement polling to request data any time it is needed.

What are websockets? #

Websockets are a communication protocol that allow the creation of persistentbidirectional communication channels between client and server.ClientServerIdentify Yourself!SSL HandshakeAuthenticateAuthorizeMake a RequestSend dataAcknowledgeEvent on Server!Send dataMake a RequestGet dataSend dataA Websockets Journey

Persistent #

  • Once established, the connection between client and server is kept-alive for a long period
    • No theoretical limit
    • Connection can be kept alive through regular pings
  • Disconnections are events that can be monitored to trigger reconnection

Bidirectional #

  • Once the connection is established, the server can send information to the client at any time.
    • No need for the client to initiate the request
  • Client can also send requests to the server

Channels #

  • Each websocket connection is actually a channel
    • Imagine a long pipe where information can flow both ways
  • Each channel is opened on a specific address, and typically, has a specific purpose
  • Each client can open multiple channels with the same server
  • Multiple clients can open channels with the same server

Points to Note #

  • Websockets is based on TCP so the server cannot broadcast messages to all clients
    • Instead, on the server, maintain a list of connnected clients and send them messages in a loop
  • Each websocket connection consumes memory so close unused connections
    • Enforce ping based check of alive clients – if no response, close the connection!
  • Websockets only concerns itself with the transport layer (on top of TCP) and makes no recommendation about the encoding of the data being transmitted.

Exercises #

Tools we need #

1. Public Websocket Server #

  • Use websocat from a terminal to connect to the Binance websocket streams
    • These endpoints are known to work:
      • wss://stream.binance.com:9443/ws/!miniTicker@arr
      • wss://stream.binance.com:9443/ws/btcusdt@depth
      • wss://stream.binance.com:9443/ws/bnbbtc@depth
  • Open another terminal/tab and connect to a different stream from Binance
  • For the really patient, check how long the connection remains open for with:date; websocat wss://stream.binance.com:9443/ws/bnbbtc@depth; date

2. Local Websocket Server #

NodeJS #

Python #

  • Follow this tutorial to set up a local websocket client and server

3. ESP32 as a Websocket Server #

  • Set up ESP-IDF on your computer
  • Build and flash the Websocket Echo Server example from ESP-IDF on the ESP32
    • You will need to configure your WiFi settings with idf.py menuconfig
    • Once booted, the ESP32 will print its ip_address. You will need this.
  • Using websocat, connect to ws://ip_address/ws
  • Once connected, type and send any string message, e.g. hello
  • Open a new terminal and repeat the websocat messaging.
    • What do you notice across the two clients?

More advanced example #

Questions #

  • What are the similarities and differences between HTTP and BLE?
  • What are the similarities and differences between Websockets and BLE?
  • How would you implement an API for client to request changes (e.g. switch on lights)?
